Power electronics converter design and packaging

Semtronics is a UK power electronics design consultancy. We design power converters for OEMs, Tier 1 suppliers and engineering firms, from the first specification to tested prototypes and manufacturing support. Our engineers have designed converters from a few watts to megawatt-scale systems.

Converters we design

  • AC-DC converters and power factor correction (PFC), single and three phase
  • Isolated and non-isolated DC-DC converters, unidirectional and bidirectional
  • On-board chargers (OBC) and V2G / V2X bidirectional chargers
  • Inductive wireless power transfer (WPT) for electric vehicles
  • SiC traction inverters and motor drives
  • Battery energy storage (BESS) and multilevel converters

What the design covers

  • Requirement capture and specification for OEMs and automotive manufacturers
  • Topology selection, simulation, schematics, PCB design and hardware prototyping
  • Magnetics design, thermal simulation and cooling system design
  • Packaging to minimise parasitic inductance and capacitance and the switching loop
  • Placement of capacitors, magnetics, PCB, heatsink and enclosure
  • Wide-bandgap (SiC and GaN) device selection, gate drive and protection
  • EMI/EMC design and compliance planning

Why work with Semtronics

You work directly with experienced power electronics engineers. We combine circuit design, magnetics, thermal, embedded control and test in one team, so your converter is designed as a complete system rather than as separate parts.

Related pages

Have a power electronics project? Contact our engineers to discuss your requirements.
