Fuel cell power electronics

A hydrogen fuel cell vehicle uses its fuel cell to generate electricity for the high-voltage battery and the traction inverter. A fuel cell does not provide a constant voltage, so a DC-DC converter is needed to match it to the battery voltage. The converter links the fuel cell, HV battery and electric drive unit and controls how much power the stack delivers.

Fuel cell converter ratings

  • Output power from a few kW to 200 kW
  • Voltage range from 150 V to 900 V
  • Bidirectional power flow, so the fuel cell can be operated in a controlled way

Design capability

  • Interleaved boost and isolated topologies with low input ripple to protect the stack
  • Stack current and voltage control integrated with the fuel cell controller
  • SiC devices, liquid cooling and high power density
  • Applications in cars, buses, trucks, marine and stationary power
Fuel cell DC-DC converter
Hydrogen fuel cell vehicle power architecture
