AC-DC converter and power factor correction (PFC)

The AC-DC stage connects your product to the grid. It sets input current quality, efficiency and much of the EMC performance. Semtronics designs single and three-phase AC-DC converters with active power factor correction for EV chargers, battery chargers and industrial power supplies.

Applications

  • On-board chargers (OBC) and off-board chargers that convert AC supply to a DC battery voltage
  • Three-phase PFC front ends for DC fast chargers and bidirectional V2G chargers
  • Single and three-phase PFC for battery charging
  • Front ends for battery energy storage (BESS) and industrial drives

Power levels

Designs at 3.3 kW, 6.6 kW, 20 kW and 40 kW, with other ratings to suit your specification.

Design capability

  • Topology selection for efficiency, cost and bidirectional operation, including totem-pole and three-phase active rectifiers
  • SiC device selection for high switching frequency and power density
  • Digital PFC control with low THD and high power factor across the load range
  • Input EMI filter design for conducted emissions compliance
  • Magnetics, thermal and liquid or air cooling design
AC-DC converter with power factor correction
